Installing Memory-Module Kits
Before you begin:
Be sure you have:
Read “Electrical Safety” on page 75 and “Handling
Static-Sensitive Devices” on page 77 (or your safety booklet).
Removed the server cover (see “Preparing to Install Options”
on page 78).
The following illustration shows the memory-board location on the
system board.
1
2
3
.1/ System board
.2/ Memory-board connector
.3/ Memory board
Chapter 4. Installing Options 115
