FC EU04 - USB External Docking Station for Removable Disk Drive
FC EU04 uses an external USB cable to connect to an external USB port. The EU04 feature code
includes a USB cable, an external power supply, and a power cord as part of the feature code.
FC EU04 provides the following parts:
46C2333 (FRU: 46C2347) - External RDX USB 3.0 Dock
05H5081 (FRU: 05H5080) - External USB 3.0 Cable (2.7 m or 8'10'')
81Y3649 (FRU: 81Y8905) - External power supply with power cord and universal plugs for all
supported geographies
39M5516 (FRU: 39M5516) - Power cord (1 m) that connects the power supply to the rack
power distribution unit
Removable disk drives
Table 61. Removable disk drives
Feature code Part number Description
1106 46C5375 160 GB Removable Disk Drive
EU08 46C5377 320 GB Removable Disk Drive
1107 46C5379 500 GB Removable Disk Drive
EU01 46C2335 1 TB Removable Disk Drive
EU15 46C2831 1.5 TB Removable Disk Drive
Purchasing additional removable disk drives
For best results, use only the removable disk drives that are shown in Table 61.
The removable disk drives are a supply item that can be ordered as a feature code. To order in the United
States and Canada, call 1-888-IBM-MEDIA. To order drives in other locations, contact your local provider
of IBM storage products or see Storage Media (http://www.storage.ibm.com/media/).
Note:
The removable disk drives are not a service item. IBM service representatives are not dispatched to
service or replace the removable disk drives.
Storing removable disk drives
Store removable disk drives in their protective containers, on a flat surface with the top side up. The
storage area must be clean and dry, must have normal room temperature, and must be away from any
magnetic fields. For best storage life, use the removable disk drives every six months.
Supported USB adapters and cables
Attention: The docking station only supports the USB cable that is provided as part of the feature code.
The docking station does not support attachment by using USB hubs, add-on USB cables, or USB cable
extenders.
The external docking station can be connected to the external, integrated USB ports on POWER7
processor-based systems or can be connected to the USB ports on 4-Port USB PCI Express Adapter (FC
2728).
The internal docking station can be connected to the internal USB port on the control panel of POWER7
processor-based systems.
86 Managing devices
