FC EU03 - USB Internal Docking Station for Removable Disk Drive
FC EU03 uses an internal USB cable to connect to the internal USB media device connector on the
system backplane of a system that supports this feature. The internal USB media device cable and
power cable are included in the feature code.
FC EU03 provides the following parts:
46C2332 (FRU: 46C2346) - Internal RDX USB 3.0 Dock
46K7435 - Internal USB media device cable (12 inch)
46K7434 - Internal power cable (11 inch) with right angle power connector
44V3429 - Two drive slide assembly rails
1621187 - Four flat blade screws
FC EU23 - USB Internal Docking Station for Removable Disk Drive
FC EU23 uses an internal USB cable to connect to the internal USB media device connector on the
system backplane of a system that supports this feature. The internal USB media device cable and
power cable are included in the feature code.
Note: The FC EU23 is not supported on IBMi systems, because IBMi does not support the split
backplane on the systems that support FC EU23.
FC EU23 provides the following parts:
46C2443 (FRU: 46C2444) - Internal 3.5" RDX USB 3.0 Dock
46K7435 - Internal USB media device cable (12 inch)
46K7434 - Internal power cable (11 inch) with right angle power connector
Requires FC 5263
DASD/Media Backplane - 3 SFF DASD/SATA DVD/HHTape. The FC 5263 is supported on the
8231-E2B system.
Note: A single mounting clip (74Y5182) is provided with the system and is not part of this FC
5263.
Removable disk drives
Table 58. Removable disk drives
Feature code Part number Description
1106 46C5375 160 GB Removable Disk Drive
1107 46C5379 500 GB Removable Disk Drive
EU01 46C2335 1 TB Removable Disk Drive
EU08 46C5377 320 GB Removable Disk Drive
EU15 46C2831 1.5 TB Removable Disk Drive
Purchasing additional removable disk drives
For best results, use only the removable disk drives that are shown in Table 58.
The removable disk drives are a supply item that can be ordered as a feature code. To order in the United
States and Canada, call 1-888-IBM-MEDIA. To order drives in other locations, contact your local provider
of IBM storage products or see Storage Media (http://www.storage.ibm.com/media/).
The removable disk drives are not a service item. IBM service representatives are not dispatched to
service or replace the removable disk drives.
Managing devices 81
