USB
1
connector
Connect
a
USB
device
to
this
connector.
Ethernet
connector
Use
this
connector
to
connect
the
server
to
a
network.
Serial
2
connector
Connect
a
9-pin
serial
device
to
this
connector.
If
you
have
an
optional
Remote
Supervisor
Adapter
II
(systems-management
adapter)
installed
in
PCI-X
slot
2,
your
server
has
additional
connectors
and
LEDs.
See
the
Option
Installation
Guide
for
more
information
about
these
connectors
and
LEDs.
In
addition,
if
you
install
the
optional
Remote
Supervisor
Adapter
II,
you
must
disconnect
the
video
cable
from
the
server
external
video
connector
and
connect
it
to
the
optional
Remote
Supervisor
Adapter
II.
Server
power
features
When
the
server
is
connected
to
an
ac
power
source
but
is
not
turned
on,
the
operating
system
does
not
run,
and
all
core
logic
is
shut
down;
however,
the
server
can
respond
to
remote
requests
to
turn
on
the
server.
The
power-on
LED
flashes
to
indicate
that
the
server
is
connected
to
an
ac
power
source
but
is
not
turned
on.
Note:
When
the
server
is
connected
to
an
ac
power
source,
the
power
supply
fan
turns
on
and
remains
on
to
provide
cooling
to
the
power
supply.
Turning
on
the
server
Approximately
20
seconds
after
the
server
is
connected
to
ac
power,
the
power-control
button
becomes
active,
and
you
can
turn
on
the
server
and
start
the
operating
system
by
pressing
the
power-control
button.
The
server
can
also
be
turned
on
in
any
of
the
following
ways:
v
If
a
power
failure
occurs
while
the
server
is
turned
on,
the
server
will
restart
automatically
when
power
is
restored.
v
If
your
operating
system
supports
the
systems-management
software
for
an
optional
Remote
Supervisor
Adapter
II,
the
systems-management
software
can
turn
on
the
server.
v
If
your
operating
system
supports
the
Wake
on
LAN
feature,
the
Wake
on
LAN
feature
can
turn
on
the
server.
v
If
an
optional
Remote
Supervisor
Adapter
II
is
installed
in
the
server,
the
server
can
be
turned
on
from
the
Remote
Supervisor
Adapter
II
user
interface.
Note:
When
4
GB
or
more
of
memory
(physical
or
logical)
is
installed,
some
memory
is
reserved
for
various
system
resources
and
is
unavailable
to
the
operating
system.
The
amount
of
memory
that
is
reserved
for
system
resources
depends
on
the
operating
system,
the
configuration
of
the
server,
and
the
configured
PCI
options.
Chapter
1.
Introducing
the
xSeries
226
Type
8648
server
11
|
|
|
|
|
|
|
|
|
