IBM 9009-22A Site And Hardware Planning

Table 54. Dimensions for rack (continued)
Width Depth Height Weight (Empty)
EIA unit
capacity
Rack with high-
end
appearance
front door and
rear door
600 mm (23.6
in.)
1201 mm (47.3
in.)
2020 mm (79.5 in.) 181 kg (398 lb) 42 EIA units
Table 55. Weight capacity limits
Characteristics Maximum weight EIA unit capacity
Dynamic (rolling) 1134 kg (2500 lb) 18 kg (40 lb) / EIA average
Static 1678 kg (3700 lb) 32 kg (70 lb) / EIA average
Seismic certied 1170 (2580 lb) 20 kg (45 lb) / EIA maximum
Table 56. Dimensions for doors
Door model Width Height Depth Weight
Standard front
door and
standard back
door
590 mm (23.2
in.)
1942 mm (76.5 in.) 31 mm (1.2 in.) 5.9 kg (13 lb)
Rear door heat
exchanger door
600 mm (23.6
in.)
1950 mm (76.8 in.) 129 mm (5.0 in.)
39 kg (85 lb) - empty
48 kg (105 lb) - lled
High-end
appearance front
door
590 mm (23.2
in.)
1942 mm (76.5 in.) 100 mm (3.9 in.) 9.1 kg (20 lb)
FC ECRC and
ECRD acoustic
front and rear
doors, black IBM
590 mm (23.2
in.)
1942 mm (76.5 in.) 115.5 mm (4.6 in) 17.7 kg (39 lb)
FC ECRC and
ECRD acoustic
front and rear
doors, black OEM
590 mm (23.2
in.)
1942 mm (76.5 in.) 110 mm (4.3 in) 17.7 kg (39 lb)
Table 57. Dimensions for side covers
Width
1
Depth Height Weight
2
12 mm (0.5 in.) 1070 mm (42.1 in.) 1942 mm (76.5 in.) 20 kg (44 lb)
1
Side covers increase the overall width of the rack by 12 mm (0.5 in.) per side, but are only used on the ends
of the rows.
2
Weight is for each side cover.
