Table 4. Adapter slot priorities and maximum adapters supported in the 9040-MR9 (continued)
Feature code Description Slot priority Maximum number of
adapters supported
2 processors 3 processors 4 processors
5735 8 Gb PCI Express
dual-port Fibre Channel
adapter (FC 5735 and
EL58); CCIN 577D)
12, 9,11,8, 10, 7 12, 9, 11, 8, 5, 10, 7, 4 12, 9, 11, 8, 5, 3, 10, 7,
4, 2
6/8/10
5748 POWER
®
GXT145 PCI
Express Graphics
Accelerator (FC 5748;
CCIN 5269)
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
5785 4-port Async EIA-232
PCIe 1X adapter (FC
5277 and 5785; CCIN
57D2)
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
5899 PCIe2 4-port 1 GbE
adapter (FC 5260, FC
5899, FC EL4L, and FC
EL4M; CCIN 576F)
6, 12, 9, 11, 8, 10, 7 6, 12, 9, 11, 8, 5, 10, 7,
4
6, 12, 9, 11, 8, 5, 3, 10,
7, 4, 2
7/9/11
EC2S PCIe3 2-port 10 Gb NIC
& RoCE SR/Cu adapter
(FC EC2R and EC2S;
CCIN 58FA)
6, 11, 8, 10, 7, 12, 9 6, 11, 8, 5, 10, 7, 4, 12,
9
6, 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
7/9/11
EC2U PCIe3 2-port 25/10 Gb
NIC & RoCE SFP28
Adapter (FC EC2U; CCIN
58FB)
6, 11, 8, 10, 7, 12, 9 6, 11, 8, 5, 10, 7, 4, 12,
9
6, 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
7/9/11
EC3B PCIe3 2-Port 40 GbE
NIC RoCE QSFP+
adapter (FC EC3B; CCIN
57BD); Adapter part
number: 00FW105
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
EC3M PCIe3 2-port 100 GbE
NIC & RoCE QSFP28
adapter (FC EC3M; CCIN
2CEC); Adapter FRU
number: 00WT078
11, 8, 10, 7 11, 8, 5, 10, 7, 4 11, 8, 5, 3, 10, 7, 4, 2 4/6/8
EC38 PCIe3 2-port 10 GbE
NIC & RoCE SFP+
Copper adapter (FC
EC37, EC38, EL3X, and
EL53; CCIN 57BC)
6, 11, 8, 10, 7, 12, 9 6, 11, 8, 10, 7, 12, 9 6, 11, 8, 10, 7, 12, 9 7/9/11
EC46 PCIe2 4-port USB 3.0
adapter (FC EC45 and
EC46; CCIN 58F9)
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
EC5B PCIe3 x8 Non-Volatile
Memory 1.6 TB SSD
NVMe adapter (FC
EC5A, EC5B, EC5G,
EC6U, and EC6V; CCIN
58FC)
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
EC5D PCIe3 x8 Non-Volatile
Memory 3.2 TB SSD
NVMe adapter (FC EC5C
and EC5D; CCIN 58FD)
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
EC5E PCIe3 x8 Non-Volatile
Memory 6.4 TB SSD
NVMe adapter (FC
EC5E, EC5F, EC6Y, and
EC6Z; CCIN 58FE)
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
EC63 PCIe4 x16 1-Port
EDR 100 GB
InniBand ConnectX-5
CAPI-capable adapter
(FC EC62 and EC63;
CCIN 2CF1)
11, 8, 10, 7 11, 8, 5, 10, 7, 4 11, 8, 5, 3, 10, 7, 4, 2 4/6/8
4Power Systems: Adapter placement for the 9040-MR9
