Table 4. Adapter slot priorities and maximum adapters supported in the 9040-MR9 (continued)
Feature code Description Slot priority Maximum number of
adapters supported
2 processors 3 processors 4 processors
EC65 PCIe4 x16 2-Port EDR
100 GB IB ConnectX-5
CAPI Capable adapter
(FC EC65; CCIN 2CF2)
11, 8, 10, 7 11, 8, 5, 10, 7, 4 11, 8, 5, 3, 10, 7, 4, 2 4/6/8
EC66 2-port 100 GB RoCE En
Connectx-5 PCIe4 x16
adapter (FC EC66; CCIN
2CF3)
11, 8, 10, 7 11, 8, 5, 10, 7, 4 11, 8, 5, 3, 10, 7, 4, 2 4/6/8
EC6J PCIe2 LP 2-Port USB
3.0 Adapter (FC EC6J
and FC EC6K; CCIN
590F); Adapter part
number: 02JD518
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
EC76 PCIe4 2-port 100 GbE
RoCE x16 adapter (FC
EC75 and FC EC76;
CCIN 2CFB); Adapter
part number: 02CM921
11, 8, 10, 7 11, 8, 5, 10, 7, 4 11, 8, 5, 3, 10, 7, 4, 2 4/6/8
EC7B PCIe4 x8 NVMe 1.6 TB
SSD NVMe Adapter (FC
EC7A, EC7B, EC7J, and
EC7K; CCIN 594A)
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
EC7D PCIe4 x8 NVMe 3.2 TB
SSD NVMe Adapter (FC
EC7C, EC7D, EC7L, and
EC7M; CCIN 594B)
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
EC7F PCIe4 x8 NVMe 3.2 TB
SSD NVMe Adapter (FC
EC7E, EC7F, EC7N, and
EC7P; CCIN 594C)
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
EJ08 PCIe3 cable adapter
for the EMX0 PCIe3
expansion drawer (FC
EJ08; CCIN 2CE2)
11, 8, 10, 7 11, 8, 5, 10, 7, 4 11, 8, 5, 3, 10, 7, 4, 2 4/6/8
EJ0J PCIe3 SAS RAID quad-
port 6 Gb adapter (FC
EJ0J and EL59); CCIN
57B4)
11, 8, 10, 7 11, 8, 5, 10, 7, 4 11, 8, 5, 3, 10, 7, 4, 2 4/6/8
EJ0K PCIe3 SAS RAID quad
port 6 Gb x8, low-prole
capable adapter (FC
EJ0K; CCIN 57B4)
12, 9, 11, 8, 10, 7 12, 9, 11, 8, 5, 10, 7, 4 12, 9, 11, 8, 5, 3, 10, 7,
4, 2
6/8/10
EJ0L PCIe3 12 GB Cache
RAID SAS quad-port 6
Gb adapter (FC EJ0L;
CCIN 57CE)
11, 8, 10, 7 11, 8, 5, 10, 7, 4 11, 8, 5, 3, 10, 7, 4, 2 4/6/8
EJ10 PCIe3 4 x8 SAS Port
adapter (FC EJ10; CCIN
57B4)
11, 8, 10, 7 11, 8, 5, 10, 7, 4 11, 8, 5, 3, 10, 7, 4, 2 4/6/8
EJ14 PCIe3 12 GB Cache
RAID PLUS SAS adapter
quad-port 6 Gb x8 (FC
EJ14; CCIN 57B1)
12, 9, 11, 8, 10, 7 12, 9, 11, 8, 5, 10, 7, 4 12, 9, 11, 8, 5, 3, 10, 7,
4, 2
6/8/10
EJ1P PCIe1 SAS Tape/DVD
dual-port 3 Gb x8
adapter (FC EJ1N and
EJ1P; CCIN 57B3)
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
EJ20 PCIe3 cable adapter
for the EMX0 PCIe3
expansion drawer (FC
EJ20; CCIN 2CF5)
11, 8, 10, 7 11, 8, 5, 10, 7, 4 11, 8, 5, 3, 10, 7, 4, 2 4/6/8
EJ27 PCIe Crypto- graphic
Coprocessor (FC EJ27
and EJ28; CCIN 476A)
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
Adapter placement for the 9040-MR95
