IBM 9040-MR9 - Page 20

Table 4. Adapter slot priorities and maximum adapters supported in the 9040-MR9 (continued)
Feature code Description Slot priority Maximum number of
adapters supported
2 processors 3 processors 4 processors
EJ32 4767-001
Cryptographic
Coprocessor (FC EJ32;
CCIN 4767)
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
EJ37 4769-001
Cryptographic
Coprocessor (FC EJ35
and EJ37 for BSC; CCIN
C0AF)
6 6 6 1/1/1
EN0A PCIe3 16 Gb 2-port
Fibre Channel adapter
(FC EL5B and FC EN0A;
CCIN 577F)
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
EN0G PCIe2 8 Gb 2-port Fibre
Channel adapter (FC
EN0F and EN0G; CCIN
578D)
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
EN0H PCIe3 4-port (10 Gb
FCoE and 1 GbE)
(FCEL38, FC EL56, FC
EN0H, and FC EN0J;
CCIN 2B93)
6, 11, 8, 10, 7, 12, 9 6, 11, 8, 5, 10, 7, 4, 12,
9
6, 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
7/9/11
EN0K PCIe3 4-port (10 Gb
FCoE and 1 GbE) copper
and RJ45 adapter (FC
EL57 and EN0K; CCIN
2CC1)
6, 11, 8, 10, 7, 12, 9 6, 11, 8, 5, 10, 7, 4, 12,
9
6, 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
7/9/11
EN0M PCIe3 4-port (10 Gb
FCoE and 1 GbE) LR and
RJ45 adapter (FC EN0M
and EN0N; CCIN 2CC0)
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
EN0S PCIe2 4-port (10 Gb + 1
GbE) SR+RJ45 adapter
(FC EN0S; CCIN 2CC3)
6, 11, 8, 10, 7, 12, 9 6, 11, 8, 5, 10, 7, 4, 12,
9
6, 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
7/9/11
EN0U PCIe2 4-port (10 Gb + 1
GbE) Copper SFP+RJ45
adapter (FC EN0U; CCIN
2CC3)
6, 11, 8, 10, 7, 12, 9 6, 11, 8, 5, 10, 7, 4, 12,
9
6, 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
7/9/11
EN0W PCIe2 2-port 10 GbE
BaseT RJ45 adapter (FC
EN0W; CCIN 2CC4)
6, 11, 8, 10, 7, 12, 9 6, 11, 8, 5, 10, 7, 4, 12,
9
6, 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
7/9/11
EN12 PCIe2 FH 4-port 8 Gb
Fibre Channel adapter
(FC EN12; CCIN EN0Y)
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
EN15 PCIe3 4-port 10 GbE SR
adapter (FC EN15 and
EN16; CCIN 2CE3)
6, 11, 8, 10, 7, 12, 9 6, 11, 8, 5, 10, 7, 4, 12,
9
6, 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
7/9/11
EN1A PCIe3 8x 2-port Fibre
Channel (32 Gb/s); (FC
EL5U, EL5V, EN1A, and
EN1B); CCIN 578F)
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
EN1C PCIe3 8x 4-port Fibre
Channel (16 Gb/s); (FCs
EL5W, EL5X, EN1C, and
EN1D; CCIN 578E)
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
EN1E PCIe3 x8 4-port Fibre
Channel (16 Gb/s); (FC
EN1E and EN1F; CCIN
579A); Adapter part
number: 02JD586
11, 8, 10, 7, 12, 9 11, 8, 5, 10, 7, 4, 12, 9 11, 8, 5, 3, 10, 7, 4, 2,
12, 9
6/8/10
6Power Systems: Adapter placement for the 9040-MR9
