Table 6. Adapter slot priorities and maximum adapters supported in the EMX0 PCIe3 expansion drawer
(continued)
Feature
code
Description EMX0 PCIe3 expansion drawer
Slot priorities
1
Maximum number of adapters
supported
2
AIX
®
Linux IBM i
EN0A PCIe3 16 Gb 2-port Fibre
Channel adapter (FC EL43,
EL5B, EN0A, and EN0B; CCIN
577F); Adapter part number:
00E3496
P1-C1, P2-C1, P1-
C4, P2-C4, P1-C2,
P2-C2, P1-C3, P2-
C3, P1-C5, P2-C5,
P1-C6, P2-C6
6 6 6
EN0G PCIe2 8 Gb 2-port Fibre Channel
adapter
P1-C2, P2-C2, P1-
C5, P2-C5, P1-C3,
P2-C3, P1-C6 P2-C6,
P1-C1, P2-C1, P1-
C4, P2-C4
6 (EL5Z - 0) 6 6 (EL5Z - 0)
EN0H PCIe3 4-port (10 Gb FCoE and
1 GbE) (FC EL38, FC EL56,
FC EN0H, and FC EN0J; CCIN
2B93); Adapter part number:
00E3498
P1-C1, P2-C1, P1-
C4, P2-C4, P1-C2,
P2-C2, P1-C3, P2-
C3, P1-C5, P2-C5,
P1-C6, P2-C6
6 (EL56 - 0) 6 0
EN0K PCIe3 4-port (10 Gb FCoE and 1
GbE) copper and RJ45 adapter
(FC EL3C, EL57, EN0K, and
EN0L; CCIN 2CC1); Adapter part
number: 00E8140 (FC EN0K)
and 00E3502 (FC EN0L)
P1-C1, P2-C1, P1-
C4, P2-C4, P1-C2,
P2-C2, P1-C3, P2-
C3, P1-C5, P2-C5,
P1-C6, P2-C6
6 (EL57 - 0) 6 0
EN0M PCIe3 4-port (10 Gb FCoE and
1 GbE) LR and RJ45 adapter (FC
EN0M and FC EN0N)
P1-C1, P2-C1, P1-
C4, P2-C4, P1-C2,
P2-C2, P1-C3, P2-
C3, P1-C5, P2-C5,
P1-C6, P2-C6
6 6 0
EN0S PCIe2 4-port (10 Gb + 1 GbE)
SR+RJ45 adapter (FC EN0S,
FC EN0T, FC EN0U, and FC
EN0V; CCIN 2CC3); Adapter part
number: 00E2715
P1-C1, P2-C1, P1-
C4, P2-C4, P1-C2,
P2-C2, P1-C3, P2-
C3, P1-C5, P2-C5,
P1-C6, P2-C6
6 6 0s
EN0U PCIe2 4-port (10 Gb + 1 GbE)
Copper SFP+RJ45 adapter (FC
EN0U; CCIN 2CC3); Adapter part
number: 00E2715; low-prole
tailstock: 00E2720
P1-C1, P2-C1, P1-
C4, P2-C4, P1-C2,
P2-C2, P1-C3, P2-
C3, P1-C5, P2-C5,
P1-C6, P2-C6
6 6 0
EN0W PCIe2 2-port 10 GbE BaseT
RJ45 Adapter
P1-C1, P2-C1, P1-
C4, P2-C4, P1-C2,
P2-C2, P1-C3, P2-
C3, P1-C5, P2-C5,
P1-C6, P2-C6
6 (EL55 - 0) 6 0
Adapter placement for the 9040-MR913
