Table 6. Adapter slot priorities and maximum adapters supported in the EMX0 PCIe3 expansion drawer
(continued)
Feature
code
Description EMX0 PCIe3 expansion drawer
Slot priorities
1
Maximum number of adapters
supported
2
AIX
®
Linux IBM i
EN12 PCIe2 FH 4-port 8 Gb Fibre
Channel adapter (FC EN12;
CCIN EN0Y); Adapter part
number 00WT107
P1-C1, P2-C1, P1-
C4, P2-C4, P1-C2,
P2-C2, P1-C3, P2-
C3, P1-C5, P2-C5,
P1-C6, P2-C6
6 6 0
EN13 PCIe Binary Synchro- nous
adapter (FC EN13 and EN14;
CCIN 576C)
P1-C6, P2-C6 0 0 1
EN15 PCIe3 4-port 10 GbE SR adapter
(FC EN15 and EN16; CCIN
2CE3); Adapter part number:
00ND466
P1-C1, P2-C1, P1-
C4, P2-C4, P1-C2,
P2-C2, P1-C3, P2-
C3, P1-C5, P2-C5,
P1-C6, P2-C6
6 6 6
EN17 PCIe3 4-port 10 GbE SFP+
copper adapter (FC EN17 and
EN18, CCIN 2CE4); Adapter part
number: 00ND463
P1-C1, P2-C1, P1-
C4, P2-C4, P1-C2,
P2-C2, P1-C3, P2-
C3, P1-C5, P2-C5,
P1-C6, P2-C6
6 6 6
EN1A PCIe3 x8 2-port Fibre Channel
(32 Gb/s)
P1-C2, P2-C2, P1-
C5, P2-C5, P1-C3,
P2-C3, P1-C6, P2-
C6, P1-C1, P2-C1,
P1-C4, P2-C4
6 (EL5U -
0)
6 6 (EL5U-0)
EN1C PCIe3 x8 4-port Fibre Channel
(16 Gb/s); (FC EL5W, EL5X,
EN1C, and EN1D; CCIN 578E);
Adapter part number: 01FT698
P1-C2, P2-C2, P1-
C5, P2-C5, P1-C3,
P2-C3, P1-C6, P2-
C6, P1-C1, P2-C1,
P1-C4, P2-C4
6 (EL5W -
0)
6 6 (EL5W -
0)
EN1E PCIe3 x8 4-port Fibre Channel
(16 Gb/s); (FC EN1E and
EN1F; CCIN 579A); Adapter part
number: 02JD586
P1-C2, P2-C2, P1-
C5, P2-C5, P1-C3,
P2-C3, P1-C6, P2-
C6, P1-C1, P2-C1,
P1-C4, P2-C4
6 6 6
EN1G PCIe3 x8 2-port Fibre
Channel (16 Gb/s) (EN1G and
EN1H; CCIN 579B); Adapter
part number: 02CM900 and
02CM903
P1-C1, P2-C1, P1-
C4, P2-C4, P1-C2,
P2-C2, P1-C3, P2-
C3, P1-C5, P2-C5,
P1-C6, P2-C6
6 6 6
EN1J PCIe4 x8 2-port Fibre Channel
(32 Gb/s); (FC EN1J and
EN1K; CCIN 579C); Adapter part
number: 02CM909
P1-C2, P2-C2, P1-
C5, P2-C5, P1-C3,
P2-C3, P1-C6, P2-
C6, P1-C1, P2-C1,
P1-C4, P2-C4
6 6 6
14Power Systems: Adapter placement for the 9040-MR9
