Before you begin: Read this entire task before completing any individual steps.
5.1
5.2
Fully extend both slide rails.
5.7
Using a screwdriver, tighten the two rack-retaining screws to secure the slide rails to
the back of the rack.
5.3
Lift the server using the handles on each side, and position the server on the
extended slide rails. Align the three holes of the inner slide of the slide rails with the
three holes on each side of the server.
C
D
5.4
Using a screwdriver, attach the inner slide of
the slide rails to each side of the server by
using the system-to-slide-rail screws . Use
a screwdriver to tighten each of the screws.
D
E
5.6
Simultaneously release the blue safety latches
located near the front of each slide rail
assembly, and slowly push the server back into
the rack.
Pull the server back out and push it in
again to make sure that the rails are aligned
correctly and that it glides smoothly.
F
Tip:
5.5
Remove the four blue knobs .B
5.8
Use safe practices when lifting.
Attach the four blue knobs to the server . The blue knobs are used temporarily to rest
the server on the slide rails for installation. These knobs will be removed after the server is
secured to the slide rails.
BA
Install the server onto the slide rail assembly
5
Before installing the server onto the slide rail assembly, ensure that the leveling feet
are extended and that the stabilizer bracket is correctly installed to prevent the rack
from falling forward.
32-55 kg (70.5-121.2 lbs)
Slide the server part of the way out of the rack. Using a screwdriver, tighten the front
two rack-retaining screws and the two latch-bracket screws on the front of the rack
to secure the slide rails.
E
A
B
C
D
F
Actual size
part 04N6485
