IBM BladeCenter HS23

IBM BladeCenter HS23 16
Table 12 lists additional supported network adapters and upgrades.
Table 12. Network adapters
Part
number
Description Slots
supported
Maximum
supported
Virtual Fabric Adapters and Upgrades
81Y3133 Broadcom 2-port 10Gb Virtual Fabric Adapter CFFh 1
90Y9310 IBM Virtual Fabric Advanced Software Upgrade (LOM) (License only) 1
81Y3120 Emulex 10GbE Virtual Fabric Adapter II for HS23 CFFh† 1
90Y9350 Virtual Fabric Advanced FOD Upgrade (License only) 1
90Y9332 Emulex 10GbE Virtual Fabric Adapter Advanced II for HS23 CFFh† 1
Converged Network Adapters
81Y1650 Brocade 2 port 10GbE Converged Network Adapter (CFFh) CFFh 1
42C1830 QLogic 2-pt 10Gb Converged Network Adapter (CFFh) CFFh 1
10 Gb Ethernet
94Y8550 10Gb LOM Interposer Card Dedicated
connector*
1
46M6168 Broadcom 10Gb Gen2 2-port Ethernet Expansion Card (CFFh) CFFh 1
46M6164 Broadcom 10Gb Gen2 4-port Ethernet Expansion Card (CFFh) CFFh 1
42C1810 Intel 10Gb 2-port Ethernet Expansion Card CFFh CFFh 1
90Y3570 Mellanox 2-port 10Gb Enet Expansion Card (CFFh) CFFh 1
1 Gb Ethernet
44W4479 2/4 Port Ethernet Expansion Card (CFFh) CFFh 1
44W4475 Ethernet Expansion Card (CIOv) CIOv 1
InfiniBand
46M6001 2-port 40Gb InfiniBand Expansion Card (CFFh) CFFh 1
† With Emulex Virtual Fabrics Adapters II for HS23 installed in a blade server, two 10 Gb Ethernet ports on the
adapter itself are routed to the chassis I/O bays 8 and 10 (unlike other CFFh cards), and two 10 Gb Ethernet ports
integrated on a blade itself are routed to the chassis I/O bays 7 and 9.
* While the 10Gb LOM Interposer card does not consume a CFFh slot, you have to remove it if you plan to install a
CFFh expansion card.
