IBM BladeCenter HS23 21

CE Mark (EN55022 Class A, EN60950-1, EN55024, EN61000-3-2, EN61000-3-3)



CISPR 22, Class A



External disk storage expansion

SAS Connectivity Modules (one or two) must be installed into the chassis to support external disk storage

expansion. Table 17 lists the SAS Connectivity Module.

Table 17. SAS Connectivity Modules

Part number Description Maximum quantity

supported per one chassis

39Y9195 SAS Connectivity Module 2

The external disk storage expansion enclosures listed in Table 18 are supported with HS23.

Table 18. External storage expansion enclosures

Part number Description Maximum quantity

supported per one blade server

172701X IBM System Storage® EXP3000 1

174712X IBM System Storage EXP2512 Express 1

174724X IBM System Storage EXP2524 Express 1

Table 19 lists the drives supported by EXP3000 external expansion enclosures.

Table 19. Drive options for EXP3000 external expansion enclosures

Part number Description Maximum quantity supported

per one enclosure

SATA 3.5" HDDs

43W7630 IBM 1 TB 7200 Dual Port SATA 3.5" HS HDD 12

49Y1940 IBM 2 TB 7200 Dual Port SATA 3.5" HS HDD 12

SAS 3.5" HDDs

44W2234 IBM 300 GB 15K 6 Gbps SAS 3.5" Hot-Swap HDD 12

44W2239 IBM 450 GB 15K 6 Gbps SAS 3.5" Hot-Swap HDD 12

44W2244 IBM 600 GB 15K 6 Gbps SAS 3.5" Hot-Swap HDD 12
