IBM eServer xSeries User Manual

101
Updated
28/02/01
Fibre Device Ports Reference
Part
Number
Description Total
Connections
Possible
Integrated
Ports
3
Mini Hubs
Possible
Mini Hubs
Installed
GBIC
Ports
GBICs
Included
3
00N6881 FAStT Host Adapter 1 1 - - - -
00N6882 FAStT500 Mini Hub
1
2 - - - 2 -
01K7296 FC Failsafe RAID Controller
10
11----
03K9307 FC Long-Wave GBIC 1 - - - - -
03K9308 FC Short-Wave GBIC 1 - - - - -
19K1121 FAStT200 Redundant RAID Controller 2 - - - 2 -
2108R3S SAN Data Gateway Router
2
1 1 - - - -
2109S08 SAN FC Switch, 8-Port 8 - - - 8 4
2109S16 SAN FC Switch, 16-Port 16 - - - 16 4
SFCU1xx
5
FC RAID Controller Unit
11
11----
35L1647 SAN FC Managed Hub 8 7 - - 1 -
19K11xx
6
FAStT200 Storage Server 2 - - - 2 -
19K11xx
7
FAStT200 HA Storage Server 4 - - - 4 -
00N69xx
8
FAStT500 Storage Server
11
16
4
-8416
1
-
00N71xx
9
FAStT EXP500 Storage Expansion Unit 4 - - - 4 -
1. Each FAStT500 Mini Hub provides two GBIC ports.
2. Single-ended SCSI.
3. Included GBICs and integrated optical ports are short-wave.
4. FAStT500 Storage Server supports up to eight non-redundant or four redundant host connections and up to eight non-redundant or four redundant storage connections.
5.
Where ’xx’ = country publication and power cord codes as follows:- UK=United Kingdom and Arabia, DK=Denmark, IS=Israel, IT=Italy, SD=Saudi
Arabia, SA=South Africa, SE=Switzerland/English, EU=countries not covered previously.
6. Where ‘xx’ represents a country specific code as follows:- 23=US/English, 24=Euro/English, 25=Euro/Spanish, 27=Euro/German, 28=Denmark/English,
29=Israel/English, 30=Italy/English, 31=South Africa/English, 32=Switzerland/English, 34=Switzerland/German, 36=UK/English. Country/Language - Line
Cords/Publications are included as indicated.
7. Where ‘xx’ represents a country specific code as follows:- 37=US/English, 38=Euro/English, 39=Euro/Spanish, 41=Euro/German, 42=Denmark/English,
43=Israel/English, 44=Italy/English, 45=South Africa/English, 46=Switzerland/English, 48=Switzerland/German, 50=UK/English. Country/Language - Line
Cords/Publications are included as indicated.
8. Where ‘xx’ represents a country specific code as follows:- 13=US/English, 14=Euro/English, 18=Denmark/English, 19=Israel/English, 20=Italy/English,
21=South Africa/English, 22=Switzerland/English, 26=UK/English. Country/Language - Line Cords/Publications are included as indicated.
9. Where ‘xx’ represents a country specific code as follows:- 36=US/English, 37=Euro/English, 41=Denmark/English, 42=Israel/English, 43=Italy/English,
44=South Africa/English, 45=Switzerland/English, 49=UK/English. Country/Language - Line Cords/Publications are included as indicated.
10. Fibre Channel Failsafe RAID Controller P/N 01K7296 was withdrawn with effect from 27/02/01.
11. Fibre Channel RAID Controller Unit P/N SFCU1xx was withdrawn with effect from 31/01/01 - and is replaced by FAStT500 Storage Server P/N 00N69xx.
Supported Cable Groups
Cable Group A (0.8 mm to 0.8 mm)
03K9310 Netfinity 2 M Ultra2 SCSI Cable
03K9311 Netfinity 4.2 M Ultra2 SCSI Cable
37L7101 Netfinity 20 M Ultra2 SCSI Cable
Cable Group D (Short-Wave Fibre)
36L9973 Netfinity Fibre Channel 1 M Cable
03K9306 Netfinity Fibre Channel 5 M Cable
03K9305 Netfinity Fibre Channel 25 M Cable
Customer supplied short-wave cable of up to 500 meters
(0.31 miles)
Cable Group E (Long-Wave Fibre)
Customer supplied long-wave cable of up to 10 kilometers
(6.2 miles)
GBIC
03K9308
Netfinity Fibre Channel Short-Wave
GBIC
1
03K9307
Netfinity Fibre Channel Long-Wave
GBIC
1. Four Netfinity Fibre Channel Short-Wave GBIC’s (P/N 03K9308)
are included with SAN Fibre Channel Switches (P/Ns 2109S08 and
2109S16).
