Fibre Array Solutions
Fibre Interconnection Guidelines
00N6881 FAStT Host Adapter - - S S S S S S S S S S -
00N6882 FAStT500 Mini Hub - E - E - E E - - - - H E
01K7296 FC Failsafe RAID Controller
7
- - - - - S S H S - - - -
19K1121 FAStT200 Redundant RAID Controller S - - - - E E - E H - - -
2108R3S SAN Data Gateway Router (single-ended) S - - - - S S - S - - - -
2109S08 SAN FC Switch, 8-Port S E S E S E E E - E E E E
2109S16 SAN FC Switch, 16-Port S E S E S E E E - E E E E
SFCU1xx
2
FC RAID Controller Unit
8
S -H--SS------
35L1647 SAN FC Managed Hub S E S E S - - E E E E E -
19K11xx
3
FAStT200 Storage Server S - - H - E E - E - - - E
19K11xx
4
FAStT200 HA Storage Server S - - - - E E - E - - - E
00N69xx
5
FAStT500 Storage Server
8
-H---EE-E---E
00N71xx
6
FAStT EXP500 Storage Expansion Unit - E - E - - - - - E E E E
03K9307 FC Long-Wave GBIC - H - H - H H H H H H H H
03K9308 FC Short-Wave GBIC - H - H - H H H H H H H H
S Short-wave connection only. See Fibre Device Ports Reference section for GBIC/Integrated port information.
L Long-wave connection only. See Fibre Device Ports Reference section for GBIC/Integrated port information
E Either Short-wave or Long-wave connections allowed. See Fibre Device Ports Reference section for GBIC/Integrated port information.
H Hardware connection. One of these devices installs directly into the other. i.e.: The FAStT500 Mini Hub (P/N 00N6882) installs directly into the FAStT500 Storage Server
(P/N 00N69xx) to provide GBIC availability
1. This device requires the use of GBICs. Purchase of GBICs may be needed in order to make connections to this device. See the Fibre Device Ports Reference section for
GBIC/Integrated port information.
2.
Where ’xx’ = country publication and power cord codes as follows:- UK=United Kingdom and Arabia, DK=Denmark, IS=Israel, IT=Italy, SD=Saudi Arabia, SA=South Africa, SE=Switzerland/
English, EU=countries not covered previously.
3. Where ‘xx’ represents a country specific code as follows:- 23=US/English, 24=Euro/English, 25=Euro/Spanish, 27=Euro/German, 28=Denmark/English, 29=Israel/English, 30=Italy/English,
31=South Africa/English, 32=Switzerland/English, 34=Switzerland/German, 36=UK/English. Country/Language - Line Cords/Publications are included as indicated.
4. Where ‘xx’ represents a country specific code as follows:- 37=US/English, 38=Euro/English, 39=Euro/Spanish, 41=Euro/German, 42=Denmark/English, 43=Israel/English, 44=Italy/English,
45=South Africa/English, 46=Switzerland/English, 48=Switzerland/German, 50=UK/English. Country/Language - Line Cords/Publications are included as indicated.
5. Where ‘xx’ represents a country specific code as follows:- 13=US/English, 14=Euro/English, 18=Denmark/English, 19=Israel/English, 20=Italy/English, 21=South Africa/English, 22=Switzerland/
English, 26=UK/English. Country/Language - Line Cords/Publications are included as indicated.
6. Where ‘xx’ represents a country specific code as follows:- 36=US/English, 37=Euro/English, 41=Denmark/English, 42=Israel/English, 43=Italy/English, 44=South Africa/English, 45=Switzerland/
English, 49=UK/English. Country/Language - Line Cords/Publications are included as indicated.
7. Fibre Channel Failsafe RAID Controller P/N 01K7296 was withdrawn with effect from 27/02/01.
8. Fibre Channel RAID Controller Unit P/N SFCU1xx was withdrawn with effect from 31/01/01 - and is replaced by FAStT500 Storage Server P/N 00N69xx.
