98
Updated
28/02/01
To access IBM information specific to your country via the World Wide Web, use address: http://www.ibm.com/pc
IBM FAStT EXP500 Configurator
FAStT EXP500 Storage Expansion Unit - Hard Disk Drive (HDD) Configurator
Total Internal
Storage
1
10,000 RPM Fibre Channel HDDs 15,000 RPM Fibre
Channel HDD
18.2 GB
(P/N 19K0652)
36.4 GB
(P/N 19K0653)
73.4 GB
(P/N 19K0654)
18.2 GB
(P/N 06P5707)
0 GB 0GB Standard on Base Model 0GB Standard on Base Models
18.2 GB 1 - - 1
36.4 GB 2 or 1 - 2
54.6 GB 3 - - 3
72.8 GB 4 or 2 - 4
73.4 GB - - 1 -
91.0 GB 5 - - 5
109.2 GB 6 or 3 - 6
145.6 GB 8 or 4 - 8
146.8 GB - - 2 -
182.0 GB 10 or 5 - 10
218.4 GB - 6 - -
220.2 GB - - 3 -
254.8 GB - 7 - -
291.2 GB - 8 - -
293.6 GB - - 4 -
327.6 GB - 9 - -
364.0 GB - 10 - -
367.0 GB - - 5 -
440.4 GB - - 6 -
513.8 GB - - 7 -
587.2GB - - 8 -
660.6 GB - - 9 -
734.0 GB (max) - - 10 -
This table does not represent all valid hard disk drive (HDD) configurations.
1. Select a total storage row and then select the quantity of HDDs from a column corresponding to the HDD of choice. Total
Internal Storage listed is within +- 0.2 GB unless otherwise noted.
Part
Number
Description RPM Height Bays
Supported
Max. Qty
Supported
19K0652 18.2 GB 10K-4 FC Hot-Swap HDD 10,000 SL 1...10 10
19K0653 36.4 GB 10K-4 FC Hot-Swap HDD 10,000 SL 1...10 10
19K0654 73.4GB 10K-4 FC Hot-Swap HDD 10,000 HH 1...10 10
06P5707 18.2 GB 15K-rpm FC Hot-Swap HDD 15,000 SL 1...10 10
External Storage Expansion Unit Form Factor
00N71xx
3
FAStT EXP500 Storage Expansion Unit
1,2
Rack (3U)
94G7448 Rack Power Cable Type C12 (3.7m)
2
-
1. The FAStT EXP500 Storage Expansion Unit includes two hot-swap, 350 W auto-ranging redundant power supplies each with it’s own
standard country power cord.
2. This unit does not include a Rack Power Cable P/N 94G7448 when shipped (for attachment to high voltage UPS or PDU). Standard country
power cord only are included. If required, order one Rack Power Cable for each power supply.
3. Where ‘xx’ represents a country specific code as follows:- 36=US/English, 37=Euro/English, 41=Denmark/English, 42=Israel/English,
43=Italy/English, 44=South Africa/English, 45=Switzerland/English, 49=UK/English. Country/Language Line Cords/Publications are included
as indicated.
