xSeries 220 I/O Options
Part
Number
Description Adapter
Length
PCI
Support
Slots
Supported
1
-
SCSI Storage Controllers
2
37L6091 ServeRAID-4L Ultra160 SCSI Controller
3
Full 32/64-bit 1...5
37L6080 ServeRAID-4M Ultra160 SCSI Controller
4
Full 32/64-bit 1...5
19K4646 PCI Wide Ultra160 SCSI Adapter
5
Half 32-bit 1...5
02K3454 PCI Fast/Wide Ultra SCSI Adapter Half 32-bit 1...5
Networking
6
Ethernet
09N9901 10/100 EtherLink Server Adapter by 3Com Half 32-bit 1...5
19K4401 Netfinity Gigabit Ethernet Adapter Half 32/64-bit 1...5
06P3601 10/100 Ethernet Server Adapter Half 32-bit 1...5
06P3701 Gigabit Ethernet SX Server Adapter (fibre optic cabling interface) Half 32/64-bit 1...5
Token Ring
7
34L0701 Token-Ring 16/4 PCI Adapter 2 with Wake on LAN
7
Half 32-bit 1...5
34L5001 16/4 Token-Ring PCI Management Adapter
7
Half 32-bit 1...5
34L5201 High-speed 100/16/4 Token-Ring PCI Management Adapter
7
Half 32-bit 1...5
Communications
8
37L14xx Serial I/O SST 8, 16 and 128 Port Adapters
9
Half 32-bit 1...5
9
Systems Management
09N75xx
10
Remote Supervisor Adapter Half 32-bit 2
1. The xSeries 220 has five full-length, 33 MHz PCI expansion slots, three 64-bit and two 32-bit.
2. xSeries 220 has an integrated Ultra160 SCSI Controller with a single internal channel and includes a five drop, multi-mode terminated LVD SCSI cable.
3. ServeRAID-4L Ultra160 SCSI Controller is powered by a 100 MHz Intel i960 processor and provides a single channel, 16 MB of ECC cache and either one internal or one external Ultra160 connection.
External connector is 0.8-mm VHDCI.
4. ServeRAID-4M Ultra160 SCSI Controller is powered by a 100 MHz Intel i960 processor and provides two channels, 64 MB of battery-backed ECC cache and two external 0.8-mm VHDCI Ultra160
connectors.
5. PCI Wide Ultra160 SCSI Adapter (P/N 19K4646) provides a single channel with one internal connector and a five-drop multi-mode terminated LVD SCSI cable and one external connector with a 0.8-mm
VHDCI connector. Only one of the two connectors may be utilised.
6. The xSeries 220 includes an integrated full-duplex, 10/100 Mbps Ethernet controller.
7. Wake on LAN function support is provided for slot 1 only.
8. xSeries 220 includes two USB ports, two high-speed serial/asynchronous ports, (NS16550A software compatible) and one high-speed parallel port supporting devices using SSP/EPP/ECP protocols adhering
to the IEEE 1284 Standard.
9. See Appendix E for details of Serial I/O options and configuration limitations. A maximum of four Serial I/O adapters (in any combination) may be installed.
10. Where ‘xx’ represents a country specific code: 86=Europe, 87=Denmark, 88=South Africa, 89=UK, 90=Switzerland, 91=Italy, 92=Israel, 85=USA.
