High Availability Application Server
This tower server is configured to act as the foundation for business critical applications, applications your business cannot afford to be without. Configured with enough disk drives
to mirror the operating system and provide a standard RAID 5 environment for data, optional hot-swap redundant power and UPS for power even during a blackout, this server
represents the leading edge in high availability. An internal tape drive is included to back up that all important asset...data. A modem could be included to allow out-of-band (non-
LAN) system management utilizing the integrated Netfinity Advanced System Management Processor.
High Availability File Server
This tower model is configured to meet the need of server consolidation. Many businesses are trying to get their arms around the dispersed departmental servers that have grown up
around the enterprise. By moving multiple servers onto one platform there is only one system to manage, both hardware and software. There is potentially less expensive for service,
software licenses, etc., and there is no need to worry about putting all your eggs in one basket because the xSeries240 is designed for high availability. This configuration includes 56
GB of internal HDD storage, features a third power supply which provides fully redundant power, a UPS to help protect the system against a momentary electricity loss, and an
internal tape drive that backs up, up to 40 GB per tape...in addition to all the standard features of the xSeries 240.
xSeries 240 / Netfinity 5600 Sample Configurations
Part Number Description Quantity Usage
471YExx Netfinity 5600 933MHz/256KB, 256MB ECC, Open, 40X, PCI 1 -
33L3060 256MB, 133MHz SDRAM ECC RDIMM 1 512MB total system memory
37L7201 9.1GB Ultra160 SCSI Hot-Swap SL HDD 2 9.1GB mirrored for NOS
37L7205 18.2GB 10K-4 Ultra160 SCSI Hot-Swap SL HDD 4
1
-
00N8017 60/120 GB 8mm M2 SCSI Tape Drive 1 -
10K2340 Media Bay Tray and LVD Cable Kit 1
37L6091 ServeRAID-4L Ultra160 SCSI Controller 1 RAID 5
33L37xx 250W Hot-Swap Redundant Power Supply 1 Full power redundancy
T31U2xx E54 Color Monitor 15” (350mm, 13.8” Viewable Image Size), stealth black
6
1-
SUP102Y APC Smart-UPS 1000 1 UPS
1.
Four HDDs are used for RAID 5 protection. Effective capacity is three HDDs or 54.6GB
Part Number Description Quantity Usage
K481Yxx xSeries 240 1 GHz/256KB, 256 MB ECC, Open, 40X, PCI 1 -
37L7204 9.1 GB 10K-4 Ultra2 SCSI Hot-Swap SL HDD 6
1
-
00N8017 60/120 GB 8-mm M2 SCSI Tape Drive 1 -
10K2340 Media Bay Tray and LVD Cable Kit 1
37L6889 ServeRAID-4H Ultra160 SCSI Controller 1 RAID 5 array, with hot-spare
33L37xx 250 W Hot-Swap Redundant Power Supply 1 Full power redundancy
T31U2xx E54 Color Monitor 15” (350-mm, 13.8” Viewable Image Size), stealth black
6
1-
SUP102Y APC Smart-UPS 1000 1 -
1.
Six HDDs are used for RAID 5 protection. One HDD is identified as a hot-spare. Effective storage capacity is four HDDs or 36.4GB
