73
Updated
28/02/01
Note: The following sample configurations are for illustration only and may not be suitable for any specific customer installation. Contact your IBM Business Partner or IBM
Marketing Representative for assistance with your specific configuration requirements.
High Availability Application Server
This tower server is configured to act as the foundation for business critical applications, applications your business cannot afford to be without. Configured with enough disk drives
to mirror the operating system and provide a standard RAID 5 environment for data, optional hot-swap redundant power and UPS for power even during a blackout, this server
represents the leading edge in high availability. An internal tape drive is included to back up that all important asset...data. A modem could be included to allow out-of-band (non-
LAN) system management utilizing the integrated Netfinity Advanced System Management Processor.
Server Consolidation
This tower model is configured to meet the need of server consolidation. Many businesses are trying to get their arms around the dispersed departmental servers that have grown up
around the enterprise. By moving multiple servers onto one platform there is only one system to manage, both hardware and software. There is potentially less expense for service,
software licenses, etc., and there is no need to worry about putting all your eggs in one basket because the Netfinity 7100 is designed for high availability. This configuration includes
109 GB of internal HDD storage, features a third power supply which provides fully redundant power, a UPS to help protect the system against a momentary electricity loss, and an
internal tape drive that backs up, up to 80 GB per tape...in addition to all the standard features of the Netfinity 7100.
Netfinity 7100 Sample Configurations
Part Number Description Quantity Usage
641YMxx Netfinity 7100 700MHz/2 MB Xeon, 256 MB ECC, Open, 40X, PCI 1 -
33L3067 Netfinity 64 MB, 100 MHz ECC SDRAM RDIMM 4 -
33L3113 Netfinity 128 MB, 100 MHz ECC SDRAM RDIMM 4 -
33L3115 Netfinity 256 MB, 100 MHz ECC SDRAM RDIMM 4 2 GB Total System Memory
10K2332 700MHz/2 MB Upgrade II with Pentium III Xeon Processor 2 Total of 3 SMP processors
37L7201 9.1 GB Wide Ultra160 SCSI Hot-Swap SL HDD 2 9.1 GB mirrored for NOS
37L7202 18.2 GB Wide Ultra160 SCSI Hot-Swap SL HDD 6
1
72 GB RAID 5 with hot-spare
00N7990 40/80 GB DLT Internal SCSI Tape Drive 1 -
37L6080 ServeRAID-4M Ultra160 SCSI Controller 1 RAID 1 for NOS, RAID 5 for data
33L37xx 250 W Hot-Swap Redundant Power Supply 1 Full power redundancy
T274Axx G78 Color Monitor 17” (454-mm, 17.9” Viewable Image Size), stealth black 1
SUP142Y APC Smart-UPS 1400 1 UPS
1. Six HDDs are used for RAID 5 protection. One HDD is identified as a hot-spare. Effective storage capacity is four HDDs or 72.8GB
Part Number Description Quantity Usage
631YMxx Netfinity 7100 700MHz/1 MB Xeon, 256 MB ECC, Open, 40X, PCI 1 -
33L3113 Netfinity 128 MB, 100 MHz ECC SDRAM RDIMM 4 768 MB Total System Memory
10K2331 700MHz/1 MB Upgrade II with Pentium III Xeon Processor 1 Total of 2 SMP processors
37L7204 9.1 GB 10K-4 Ultra160 SCSI Hot-Swap SL HDD 2 9.1 GB mirrored for NOS
3L7205 18.2 GB 10K-4 Ultra160 SCSI Hot-Swap SL HDD 8
1
109 GB RAID 5 with hot-spare
37L6080 ServeRAID-4M Ultra160 SCSI Controller 1 RAID 1 for NOS, RAID 5 for data
34L1501 Netfinity 10/100 Ethernet PCI Adapter 2 2 Total of 3 Ethernet connections
00N7990 40/80 GB DLT Internal SCSI Tape Drive 1 -
33L37xx 250 W Hot-Swap Redundant Power Supply 1 Full Power Redundancy
T274Axx G78 Color Monitor 17” (454-mm, 17.9” Viewable Image Size), stealth black 1 -
SUP142Y APC Smart-UPS 1400 1 UPS
1. Eight HDDs are used for RAID 5 protection. One HDD is identified as a hot-spare. Effective storage capacity is six HDDs or 109.2GB
