IBM F50 RS/6000 7025

Replacing Both the Front and Side Covers
1. Reinstall the side cover:
a. Align the pins on the rear of the side cover with the two hinges on the rear of
the system. Open the side cover to a 90 degree angle.
b. Slide the side cover down.
c. Push the side cover to close it.
5-96 IBM RS/6000 7025 F50 Series User's Guide
