FRU Name
AIX
Location Code
Physical
Location Code
Physical
Connection
Logical
Identification
Card in PCI Slot
1P
20-58 to 20-5F P2-I1 I/O Planar
Connector J1
Host Bridge
ID01, Device 01
Card in PCI Slot
2P
20-60 to 20-67 P2-I2 I/O Planar
Connector J2
Host Bridge
ID01, Device 02
Card in PCI Slot
3P
10-68 to 10-6F P2-I3 I/O Planar
Connector J3
Host Bridge
ID00, Device 03
Card in PCI Slot
4P
10-70 to 10-77 P2-I4 I/O Planar
Connector J4
Host Bridge
ID00, Device 04
Card in PCI Slot
5P
10-78 to 10-7F P2-I5 I/O Planar
Connector J5
Host Bridge
ID00, Device 05
Card in PCI Slot
6P
30-60 to 30-67 P2-I6 I/O Planar
Connector J6
Host Bridge
ID02, Device 02
Card in PCI Slot
7P
30-68 to 30-6F P2-I7 I/O Planar
Connector J7
Host Bridge
ID02, Device 03
Card in PCI Slot
8P
30-70 to 30-77 P2-I8 I/O Planar
Connector J8P
Host Bridge
ID02, Device 04
Card in PCI Slot
9P
30-78 to 30-7F P2-I9 I/O Planar
Connector J9P
Host Bridge
ID02, Device 05
Card in ISA Slot
8I
01-01 or 01-02 P2-I8 I/O Planar
Connector J81
Card in ISA Slot
9I
01-01 or 01-02 P2-I9 I/O Planar
Connector J91
SCSI Devices
Base CD-ROM
(Bay A1)
10-60-00-6, 0 P2-Z1-A6 Primary SCSI
Bus ID 6 (refer
to the note at
the end of this
table)
Media Device in
Bay B1
10-60-00-4, 0 P2-Z1-A4 Primary SCSI
Bus ID 4 (refer
to the note at
the end of this
table)
Media Device in
Bay B2
10-60-00-5, 0 P2-Z1-A5 Primary SCSI
Bus ID 5 (refer
to the note at
the end of this
table)
Chapter 6. Using the Online and Standalone Diagnostics 6-17
