Table 5. Card positions for Models 830/SB2 - FC 9074 Base I/O Tower, and Models 840/SB3 - FC

9079 Base I/O Tower

Bus number

Multi-adapter

bridge number

in DSA

Multi-adapter bridge

function number in

DSA Item DSA points to:

Position label and PCI

data width

xxxx (assigned by

LIC)

1 0 PCI IOP or IOA card C01 (64 bit)

xxxx (assigned by

LIC)

1 2 PCI IOP or IOA card C02 (64 bit)

xxxx (assigned by

LIC)

1 4 PCI IOP or IOA card C03 (64 bit)

xxxx (assigned by

LIC)

1 6 PCI IOP or IOA card C04 (64 bit)

xxxx (assigned by

LIC)

1 F Multi-adapter bridge CB1

xxxx (assigned by

LIC)

1 0 PCI IOP or IOA card C05 (64 bit/INS)

xxxx (assigned by

LIC)

1 2 PCI IOP or IOA card C06 (32 bit)

xxxx (assigned by

LIC)

1 3 PCI IOP or IOA card C07 (32 bit)

xxxx (assigned by

LIC)

1 4 PCI IOP or IOA card C09 (64 bit)

xxxx (assigned by

LIC)

1 6 PCI IOP or IOA card C10 (64 bit)

xxxx (assigned by

LIC)

1 F Multi-adapter bridge CB1

xxxx (assigned by

LIC)

2 0 PCI IOP or IOA card C11 (64 bit/INS)

xxxx (assigned by

LIC)

2 2 PCI IOP or IOA card C12 (32 bit)

xxxx (assigned by

LIC)

2 3 PCI IOP or IOA card C13 (32 bit)

xxxx (assigned by

LIC)

2 4 PCI IOP or IOA card C14 (64 bit)

xxxx (assigned by

LIC)

2 6 PCI IOP or IOA card C15 (64 bit)

xxxx (assigned by

LIC)

2 F Multi-adapter bridge CB1

Table 6. Card positions for Models 870 and 890 - Base I/O Tower (FC 9094 and FC 8094 bottom

unit), FC 5094, FC 5088 or FC 0588, and FC 8094 (top unit) Expansion I/O Unit (For FC 5094 and

8094, see Servicing notes (See page 65) above)

Analyze hardware problems 67
