IBM iSeries 270 Hardware Problem Analysis And Isolation

Bus number
Multi-adapter bridge
number in DSA
Multi-adapter bridge
function number in
DSA Item DSA points to:
Position label and
PCI data width
001 - Models 870 and
890 Base I/O Tower
only (FC 9094 and
FC 8094 bottom unit)
7 0 Service processor
(FC 9074, FC 9079
only)
CB1
v 001 - Models 870
and 890 Base I/O
Tower only (FC
9094 and FC 8094
bottom unit)
v Otherwise: xxxx
(assigned by LIC)
2 0 and 1 PCI IOP or IOA card C01
v 001 - Models 870
and 890 Base I/O
Tower only (FC
9094 and FC 8094
bottom unit)
v Otherwise: xxxx
(assigned by LIC)
2 2 and 3 PCI IOP or IOA card C02
v 001 - Models 870
and 890 Base I/O
Tower only (FC
9094 and FC 8094
bottom unit)
v Otherwise: xxxx
(assigned by LIC)
2 4 and 5 PCI IOP or IOA card C03
v 001 - Models 870
and 890 Base I/O
Tower only (FC
9094 and FC 8094
bottom unit)
v Otherwise: xxxx
(assigned by LIC)
2 6 and 7 IOA card C04
v 001 - Models 870
and 890 Base I/O
Tower only (FC
9094 and FC 8094
bottom unit)
v Otherwise: xxxx
(assigned by LIC)
2 F Multi-adapter bridge CB1
v 0002 - Models 870
and 890 Base I/O
Tower only (FC
9094 and FC 8094
bottom unit)
v Otherwise: xxxx
(assigned by LIC)
2 0 and 1 PCI IOP or IOA card C05
68 iSeries: iSeries Server 270, 800, 810, 820, 825, 830, 840, 870, 890, SB2, and SB3 Hardware Problem Analysis and Isolation
