Index Part
number
Units Description
13 21H7719 AR Bulk power
14 1621811 2 Screw, M4 (10mm)
15 86G6045 AR Filler
16 1621811 2 Screw, M4 (10mm)
17 21H6959 2 Air moving device (AMD) assembly (AMD B01 and AMD B02)
18 1621811 4 Screw, M4 (10mm)
19 21H7516 1 EMC access plate, bulk power
20 1621811 4 Screw, M4 (10mm)
Final assembly, rear - Models 840 and SB3 Processor Tower: For use by authorized service providers.
Figure 1. Final assembly, rear - Models 840 and SB3 Processor Tower
Table 1. Final assembly, rear - Models 840 and SB3 Processor Tower
414 Hardware (Remove and Replace; Part Locations and Listings)
