Index Part number Units Description
1 23L3366 1 EMC access plate
2 1621811 2 Screw, M4 (10mm)
3 23L3427 1 EMC bracket, left
4 1621811 17 Screw, M4 (10mm)
5 23L3428 1 EMC bracket, top
6 1621811 5 Screw, M4 (10mm)
7 23L3385 1 Cage assembly rear
8 1621811 13 Screw, M4 (10mm)
9 1624766 8 Screw
10 23L3447 1 EMC access plate
11 1621811 5 Screw, M4 (10mm)
12 23L3368 1 EMC access plate
13 1621811 3 Screw, M4 (10mm)
Figure 2. Final assembly, rear - Models 840 and SB3 Processor Tower, continued
Analyze hardware problems 415
