Final
assembly
—
FC
5078,
FC
5088:
For
use
by
authorized
service
providers.
Figure
1.
Final
assembly
—
FC
5078,
FC
5088
T
able
1.
Final
assembly
—
FC
5078,
FC
5088
Index
Part
number
Units
Description
1
04N4523
1
To
p
wrap
assembly
2
00G1268
4
Screws,
M4X
3
04N4499
1
Rear
EMC
shield
Analyze
hardware
problems
467
478
480
