IBM iSeries 800 Analyze Hardware Problems (System Reference Codes

Reference Code Description/Action Perform all actions before exchanging Failing Items Failing Item
9041 Invalid Load Type
The down load was successful, but the wrong type of Licensed Internal
Code was loaded. The operation was attempted again but was not
successful. Exchange the failing items for the node reporting the fault.
AJDG301
TWRCARD
9042 EEPROM Failure
The EEPROM in an SPCN node cannot be written successfully.
Exchange the SPCN node reported in the failure.
TWRCARD
9043 Download Failure
The Licensed Internal Code download to an SPCN node was completed
but was not successful.
Exchange the failing SPCN node.
TWRCARD
9046 QDS Packet Sequence Error
The Packet Sequence number is wrong. The download was stopped.
TWRCARD
9047 QDS Block Sequence Error
The Block Sequence number is wrong. The download was stopped.
TWRCARD
9048 The SPCN ROS and EEPROM LIC is not compatable.
The LIC levels in the nodes ROS and EEPROM are not compatible.
Exchange the failing items for the failing node.
TWRCARD
AJDG301
9080 Undefined Status Code
An SPCN node returned an unknown status code.
Exchange the failing SPCN node.
TWRCARD
BACKPLN
90F0 A frame was dropped from the SPCN configuration.
A frame was dropped from the SPCN configuration. This is usually caused
by a loss of ac power or a problem with the frame-to-frame cable.
TWRCARD
CBLALL
90F1 A frame was added to the SPCN configuration.
No action required. This reference code is logged for information only.
9100 Battery capacity test completed.
No action required. This reference code is logged for information only.
9101 VLIC-SPCN Timeout
A Licensed Internal Code timeout occurred. The SPCN failed to respond to
a Licensed Internal Code command.
TWRCARD
CTLPNL
SVCPROC
9102 Assign Permanent Address command failure
A node failed to perform an Assign Permanent Address command.
TWRCARD
9103 Download Initialize Timeout
An SPCN node failed to enter the download state after an Initialize for
Download command.
Exchange the failing SPCN node.
TWRCARD
1xxx
System Reference Codes 49
