Position FRU name
Possible failing
component
Type, CCIN, or part number
(use the Type, model, and
part number list to
determine the part number
when the type or CCIN are
given.)
Remove and replace/recovery
procedure
MB1 System unit
backplane
1. Service
processor
2. IOP
3. Card enclosure
or backplane
4. Clock card
5. SPCN card
6. SI I/O adapter
7. System unit
backplane
8. SI ring
connection
9. Multi-adapter
bridge (all)
282D (See page 526)
Note: Embedded IOP (type
284C) is exchanged with the
282D system unit backplane
part.
Go to Model 820 - System unit
backplane - MB1 and power
distribution board - PB1 (PB1
and MB1 are included in the
TWRCARD)
D01 to
D12
Disk unit Disk unit See the Type, model, and part
number list.
Go to Recovery procedures.
D13 Optical device Optical device See the Type, model, and part
number list.
Go to Model 820 - Removable
media - D13 and D14.
D14 Tape unit Tape unit See the Type, model, and part
number list.
Go to Model 820 - Removable
media - D13 and D14.
DB1 Device board Device board See the Type, model, and part
number list.
Go to Model 820 - Device board
- DB1 and DB2.
DB2 Device board Device board See the Type, model, and part
number list.
Go to Model 820 - Device board
- DB1 and DB2.
P01, P02,
P03
Power supply Power supply See Final assembly — Model
820
Go to Model 820 - Power supply
- P01, P02, and P03.
PB1 Power
distribution
board
Power distribution
board
See MB1 (See page 252) Go to Model 820 - System unit
backplane - MB1 and power
distribution board - PB1 (PB1
and MB1 are included in the
TWRCARD).
B01 to
B04
Air moving
device (AMD)
AMD See Final assembly - Model
820.
Go to Model 820 - AMD - B01
through B04.
NB1 Control panel Control panel 247F (See page 523) Go to Model 820 - Control panel
- NB1.
M01 Memory Riser
Card
Memory Riser
Card
2884 (See page 527) or
memory riser filler card 263D
(See page 524)
Go to Model 820 - Memory.
M01
daughter
cards
Memory DIMM See Figure 1.
2884 memory card
(See page 364) in
the Memory
locations and
placement rules
topic.
3002 (See page 528), 3004,
3005, 3006, 3007, 3009 (See
page 528)
Go to Model 820 - Memory.
252 Hardware (Remove and Replace; Part Locations and Listings)
