Possible failing
component FRU name Position
Type or
CCIN
number
(see the
Type,
model, and
part number
list)
Remove and
replace
procedure
Additional
comments
HSL cables, loop 257
(either optical or HSL-2)
v BUSCBL1 - optical
HSL cable
v BUSCBL2 - copper
HSL-2 or HSL hybrid
cable
v BUSCBL3 - copper
HSL-2 or HSL hybrid
cable
v BUSCBLx
HSL cable and
connections loop
257
C08, ports
B0-B1
See the
Type, model,
and part
number list
Go to HSL cables
- concurrent
HSL Interposer, loop 256
v BUSCBL1 - optical
interposer
v BUSCBL2 - copper
interposer
v BUSCBL3 - copper
interposer
HSL interposer
card, loop 256
C09 See the
Type, model,
and part
number list
Go to Model 825 -
Cards (dedicated)
HSL cables, loop 256
(either optical or HSL-2)
v BUSCBL1 - optical
HSL cable
v BUSCBL2 - copper
HSL-2 or HSL hybrid
cable
v BUSCBL3 - copper
HSL-2 or HSL hybrid
cable
v BUSCBLx
HSL cable and
connections, loop
256
C09, ports
A0-A1
See the
Type, model,
and part
number list
Go to HSL cables
- concurrent
IOA PCI card C10 See the
Type, model,
and part
number list
Go to Model 825 -
Cards (concurrent)
v IOA
v IOP
PCI card C10 See the
Type, model,
and part
number list
Go to Model 825 -
Cards (concurrent)
IOP PCI card C12 See the
Type, model,
and part
number list
Go to Model 825 -
Cards (concurrent)
v System processor
v memory riser
Processor /
memory card
C13 25DC (See
page 524)
Go to Model 825 -
Cards (dedicated)
258 Hardware (Remove and Replace; Part Locations and Listings)
