Index Part number Units Description
1 NONUM AR Removable media assembly
(see the Type, model, and
part number list)
2 21P7315 1 Media cage assembly
3 75G2878 2 Screw
4 53P2858 AR Power supply
4 21P7331 AR Filler, power supply
5 53P1387 AR Disk unit cage assembly
6 75G2878 4 Screw, mounting
6 04N3392 2 Screw, rear mounting
7 21P5393 AR Disk unit
8 24L1827 AR EMC shield, disk unit
8 24L1729 AR Filler blank, disk unit
8 75G2878 4 Screw
Figure 2. Final assembly - Model 825, continued
388 Hardware (Remove and Replace; Part Locations and Listings)
