Table 2. Final assembly - Model 825, continued
Index Part number Units Description
9 21P7333 1 Control panel assembly
10 21P7375 AR Air moving device (AMD) assembly
10 21P7330 AR Filler, AMD assembly
11 21P7300 1 Processor enclosure assembly
12 75G2878 6 Screw
13 21P7327 1 Bracket, cable support
14 75G2878 2 Screw
15 21P7345 1 Bracket, PCI front
16 75G2878 5 Screw, mounting
17 21P7307 1 Processor enclosure cover
Analyze hardware problems 389
