Index Part number Units Description
6 24L1078 1 Front filler plate
7 1621811 2 Screw, M4 (10mm)
8 24L1069
24L1071
1 Front cover
Hinge pin, top
Cover assembly - Models 870 and 890 Processor Tower: For use by authorized service providers.
Figure 1. Cover assembly - Models 870 and 890 Processor Tower
Table 1. Cover assembly - Models 870 and 890 Processor Tower
Index Part number Units Description
1 44P0127 1 Cover assembly, back
2 11P4106 2 Hinge, back cover
3 2665525 4 Screw,
4 44P0126 2 Cover, right-side
5 54G2882 3 Screw,
Analyze hardware problems 433
