Index Part number Units Description
6 44P0125 2 Cover, left-side
7 54G2882 3 Screw,
8 11P3535 2 Hinge, front cover
9 2665525 4 Screw
10 53P2794 1 Cover assembly, front
Final assembly - FC 9094 Base I/O Tower: For use by authorized service providers.
Figure 1. Final assembly (front) - FC 9094 Base I/O Tower
Table 1. Final assembly (front) - FC 9094 Base I/O Tower
434 Hardware (Remove and Replace; Part Locations and Listings)
