Index Part number Units Description
5 NONUM 1 Removable media cage
assembly
6 1621811 2 Screw, M4 (10mm)
7 1621817 2 Screw
8 24L1067 1 Center support bracket
9 1621811 2 Screw, M4 (10mm)
10 NONUM AR Five disk unit cage
assembly
11 1621811 12 Screw, M4 (10mm)
12 1621817 6 Screw
13 AR Disk unit assembly. See
Type, model, and part
number list.
Figure 3. Final assembly (front) - FC 9094 Base I/O Tower, (continued)
Analyze hardware problems 437
