Failing item code Description/Action
FI00132 FI00132 indicates that one of the IOAs is the failing item.
Perform Bus-PIP5 to isolate the failing IOA.
FI00141 FI00141 indicates that the IOP for the 7208 tape drive is the failing item.
The failing IOP is the type 2621 IOP.
FI00142 This failing item is in a migrated tower. See the failing item table for this failing item in the
Migrated Expansion Tower Problem Analysis, Repair and Parts manual on the V5R1
Supplemental Manuals web site .
FI00180 This failing item is in a migrated tower. See the failing item table for this failing item in the
Migrated Expansion Tower Problem Analysis, Repair and Parts manual on the V5R1
Supplemental Manuals web site .
FI00182 For Models 270 and 820, FI00182 indicates that the local optical link card is the failing item.
For Models 830, 840, SB2, and SB3, FI00182 indicates that the SPD optical bus driver is
the failing item.
v If the fifth character of word 5 (xxxx xxxx) is 1, 5, 9, or D—2686 (266 MB/s)
v If the fifth character of word 5 (xxxx xxxx) is 3, 7, B, or F—2688 (1062 MB/s)
FI00185 FI00185 indicates that the 12-port ASCII workstation attachment cable is the failing item.
FI00186 For the Model 270 and 820, FI00186 indicates that the optical cable in the top position (even
bus) of the optical link card is the failing item. For the Model 830, 840, SB2, and SB3,
FI00186 indicates that the optical cable in the top position (lower number bus) of the SPD
optical Bus Driver is the failing item.
FI00187 FI00187 indicates that the optical cable configuration is the failing item.
Perform Bus PIP1 in Migrated Expansion Tower Problem Analysis, Repair and Parts manual
on the V5R1 Supplemental Manuals web site to correct the problem.
FI00189 For the Model 270 and 820, FI00189 indicates that the bus extension card configuration is
the failing item.
For the Model 830, 840, SB2, and SB3, FI00189 indicates that the local SPD bus adapter
configuration is the failing item.
Perform Bus PIP1 in the Migrated Expansion Tower Problem Analysis, Repair and Parts
manual on the V5R1 Supplemental Manuals web site to correct the problem.
FI00200 FI00200 indicates that the AC module or the removable power cable is the failing item.
The following list shows the possible failing AC modules (see Type, model, and part number
list for part numbers):*
v System unit — part SPNLCRD
v System unit expansion (FC 5070, 5072), storage expansion tower (FC 5080, 5082)
v System unit expansion (FC 5071, 5073), storage expansion tower (FC 5081, 5083)
See Determine line cord, plug, and receptacle type in the Plan for hardware and software
topic in Information Center, to determine the power cable part number for systems in your
country or region. This information is also available in the >Plan for hardware and software
book under the Power topic.
Analyze hardware problems 253
