IBM iSeries 820 Hardware Problem Analysis And Isolation

v Memory DIMM type numbers for Model 270, 820, 830, and SB2 (See page )
v Processor and clock card type numbers for Models 830, SB2, and 840, SB3 (See page )
v Memory card type numbers for Models 830, SB2, and Models 840, SB3 (See page )
v Network Interface Controller (NIC) card for Models 830, SB2, and 840, SB3 (See page )
for
820, 830, SB2, 840, and SB3
Model Processor feature code Backplane type Location
270 22A2, 22A4, 22A5, 2422 2249 MB1
270 23E7 25B9 MB1
270 23F0, 23F1, 2452 25BA MB1
270 22A7, 22A8, 22AA, 22AB, 23F4,
23F5, 2423, 2424, 2454
282F MB1
270 2301, 2302 224A MB1
820 All 282D MB1
830, SB2 All 281A MB1
840, SB3 All 282B MB1
r 820
Model Processor feature code Processor type Location
270 22A2, 22A4, 22A5, 2422 Note: The processor is
embedded in the system
backplane (2249).
MB1
270 2301, 2302 Note: The processor is
embedded in the system
backplane (224A)
MB1
270 23E7 Note: The processor is
embedded in the system
backplane (25B9)
MB1
270 23F0, 23F1, 2452 Note: The processor is
embedded in the system
backplane (25BA)
MB1
270 22A7, 22A8, 2423 24A0 M02
270 22AA, 22AB, 2424 24A2 M02
270 23F4, 23F5, 2454 25BD M02
820 23A1, 23A2, 23A3, 23A4 244A M03
820 23A9, 23AA, 23AB, 23AC, 23AD,
2425
24A0 M03
820 23B1, 23B2, 23B3, 23B4, 23B5,
23B6, 2426
244D M03
820 23B8, 23B9, 23BA, 23BB, 23BC,
23BD, 23BE, 2427
244E M03
820 243C, 243D, 243E, 243F 224B M03
820 0150, 2456, 249B, 249C, 249D,
249E, 24A8, 24A9, 24AA, 24AB,
24AC
25BC M03
820 0151, 2457, 24B0, 24B1, 24B2,
24B3, 24B4, 24B5
25BD M03
312 iSeries: iSeries Server 270, 800, 810, 820, 825, 830, 840, 870, 890, SB2, and SB3 Hardware Problem Analysis and
Isolation
