IBM iSeries 820 Hardware Problem Analysis And Isolation

Model Processor feature code Processor type Location
820 0152, 2458, 24B8, 24B9, 24BA,
24BB, 24BC, 24BD, 24BE
25BE M03
r 820, 830, and SB2
Model Processor feature code Memory DIMM type Location
270 22A2, 22A4, 22A5, 2422 3022, 3024, 3025, 3026 A-H
270 23E7, 23F0, 23F1, 2452 3031, 3032, 3033, 3034 A-H
270 2301, 2302 3022, 3024, 3025, 3026,
3027, 3029
A-H
270 22A7, 22A8, 22AA, 22AB, 2423,
2424
3022, 3024, 3025, 3026 M01-s or M02-s
270 23F4, 23F5, 2454 3022, 3024, 3025, 3026,
3027, 3029
M01-s or M02-s
820 All 3002, 3004, 3005, 3006 M01-s, M02-s, or M03-s
820 0150, 0151, 0152, 243F, 243E,
243D, 243C, 2456, 2457, 2458,
249B, 249C, 249D, 249E, 24A8,
24A9, 24AA, 24AB, 24AC, 24B0,
24B1, 24B2, 24B3, 24B4, 24B5,
24B8, 24B9, 24BA, 24BB, 24BC,
24BD, 24BE
3007, 3009 M01-s, M02-s, or M03-s
830 All 3002, 3004, 3005, 3006,
3007
M02-s or M05-s
SB2 All 300F M02-s or M05-s
Models 830, SB2, and 840, SB3
Model Processor feature code Processor or clock card
type
Location
830 23C1, 23C2, 23C3, 23C4, 23C5
v Processor card: 245C
v Clock card: 25AB
v Processor card: M03
or M04
v Clock card: M06A
830 23D1, 23D2, 23D3, 23D4, 23D5,
23D6, 23D8, 23D9, 23DA, 23DB,
23DC, 23DD, 23DE, 24D8, 24D9,
24DA, 24DB 24DC, 24DD, 24DE,
26A8, 26A9, 26AA, 26AB, 26AC,
26AD, 26AE
v Processor card: 245D
v Clock card: 25AD
v Processor card: M03
or M04
v Clock card: M06A
SB2 2315
v Processor card: 245D
v Clock card: 25AD
v Processor card: M03
or M04
v Clock card: M06A
SB3 All
v Processor card:
– 245F
– 245E
v
Clock card:
– 25AA/25AF (See the
Note (See page )
below)
v Processor card:
– Card 0 (Location
M05)
– Card 1, 2, 3
(Location M18,
M06, M16)
v
Clock card: M19
Analyze hardware problems 313
