IBM iSeries 820 Hardware Problem Analysis And Isolation

Model Processor feature code Processor or clock card
type
Location
840 23E8, 23E9, 23EA, 23EB, 23EC,
23ED, 23EE, 23F8, 23F9, 23FA,
23FB, 23FC, 23FD, 23FE, 23FF,
24C0, 24C1, 24C2, 24C3, 24C4,
24C5, 24C6, 24C8, 24C9, 24CA,
24CB, 24CC, 24CD, 24CE, 24D0,
24D1, 24D2, 24D3, 24D4, 24D5,
24D6, 24D7
v Processor card:
– 245F
– 245E
v
Clock card: 25AA/25AF
(See Note (See page )
below)
v Processor card:
– Card 0 (Location
M05)
– Card 1,2,3
(Location M18,
M06, M16)
v
Clock card: M19
840 26B0, 26B1, 26B2, 26B3, 26B4,
26B5, 26B6, 26B8, 26B9, 26BA,
26BB, 26BC, 26BD, 26BE, 26BF,
26C0, 26C1, 26C2, 26C3, 26C4,
26C5, 26C6, 26C7, 26C8, 26D0,
26D1, 26D2, 26D3, 26D4, 26D5,
26D6, 26D7, 26D8
v Processor card:
– 246F
– 246E
v
Clock card: 25AA/25AC
(See the Note (See page
) below)
v Processor card:
– Card 0 (Location
M05)
– Card 1,2,3
(Location M18,
M06, M16)
v
Clock card: M19
Note: The Model 840/SB3 clock card consists of CCIN 25AA as the mother card and has either
CCIN 25AF or 25AC as the daughter card.
SB2, and Models 840, SB3
Model Processor feature code Memory card type Location
830, SB2 All 2881 M02 or M05
840 All 3195, 3196, 3197, 3198, 3612, 3613, 3614 M01-03, M08-15, M20-24
SB3 All 319A, 31A1 M01-03, M08-15, M20-24
for Models 830, SB2, and 840, SB3
Model Processor feature code HSL controller type Location
830, SB2 All 2732, 2754, 2758 M06
840, SB3 All 2737, 2755, 2759, 2770 M17
Instructions for Models 800, 810, 825, 870, and 890
There is a hardware failure, or the system is not able to give configuration or hardware information. The
following tables give the CCIN numbers for the FRUs associated with processor and memory errors. See
Locations and addresses for the model you are working on. Use the FRU locations and failing items table
to find additional information, including the component on which the failing item resides, a link to the part
number information for that component, and a link to remove and replace instructions.
If the system is active, see the Service Action Log for further information and analysis on the hardware
failure. If the system is not active, and the SRC documentation sent you here, use the Unit reference code
in the following tables to identify the failing item. The tables include:
v Processor configuration for Models 800 and 810 (See page )
v Processor configuration for Model 825 (See page )
v Processor configuration for Models 870 and 890 (See page )
v Memory information for Models 800, 810, 825, 870, and 890 (See page )
v System backplane information for Models 800, 810, 825, 870, and 890 (See page )
v Clock card information for Models 870 and 890 (See page )
v Cache card information for the Models 870 and 890 (See page )
314 iSeries: iSeries Server 270, 800, 810, 820, 825, 830, 840, 870, 890, SB2, and SB3 Hardware Problem Analysis and
Isolation
