v Network Interface Controller (NIC) card information for Models 800, 810, 825, 870, and 890 (See page )
Table 14. Processor configuration for Models 800 and 810
Use the following bulleted information to determine the failing item given in the reference code. Then, use
the table below to determine the CCIN number of that FRU.
v All processors are located on the system unit backplane, except for systems with processor feature
codes 7428 and 7430. Those systems have processors located in M02.
v All processor capacity cards are located behind the control panel.
Model and processor feature code
Processor capacity
card CCIN Interactive card CCIN CPU 0 VPD CCIN
800 7400 7400 NA 25B9
800 7408 7408 NA 25BA
810 7404 7404 NA 25BA
810 7406 7406 NA 25BA
810 7407 7407 NA 25BA
810 7409 7409 NA 25BA
810 7410 7410 NA 25F0
810 7412 7412 NA 25F0
810 7428 7428 NA 25EB
810 7430 7430 NA 25EB
Table 15. Processor configuration for Model 825
Use the following list to determine the failing item given in the SRC. Then, use the table below to
determine the CCIN number of that FRU. The following information is included in this list: Reference code,
FRU description, and location:
v x003 is a processor card in location C13
v x004 is a processor card in location M01
v x005 is a processor card in location M02
v x00E is a processor capacity card in location NB1A
Model and processor
feature code
Processor
capacity card
CCIN
Interactive
card CCIN
CPU 0 VPD
CCIN
CPU 1 VPD
CCIN
CPU 2 VPD
CCIN
825 7416 7416 NA 25DC 25DC 25DC
825 7418 7418 NA 25DC 25DC 25DC
825 7439 7439 NA 25DC 25DC 25DC
Table 16. Processor configuration for Models 870 and 890
Use the following list to determine the failing item given in the SRC, then use the table below to determine
the CCIN number of that FRU. The following information is included in this list: Reference code, FRU
description, and location:
v x003 is a Processor MCM in location M21
v x004 is a Processor MCM in location M11
v x005 is a Processor MCM in location M16
Analyze hardware problems 315
