IBM iSeries 820 Hardware Problem Analysis And Isolation

Unit reference code Power supply
7x03 5073, 5077, 5083
This ends the procedure.
6. Is the SRC 1xxx 2131, 2240, or 2311?
v No: Continue with the next step.
v Yes: The failing item is power supply 1 on a base expansion unit:
– FC 5033 - part 21H9364
– FC 5034 (without expansion unit) and FC 5035 (without expansion unit) - part 21H9364
– FC 5034 (with expansion unit) and FC 5035 (with expansion unit) - part 44H7779
Note: FC 5035 may contain up to four power supplies. The reference code that sent you here
refers to the power supply on the base expansion unit. See Expansion Unit Locations and
Addresses in the Migrated Expansion Tower Problem Analysis, Repair and Parts manual on the
V5R1 Supplemental Manuals web site
.
This ends the procedure.
7. Is the SRC 1xxx 2132, 2142, 2152, 2212, 2312, or 2332?
v No: Continue with the next step.
v Yes: The failing item is power supply 2 on a internal expansion unit: FC 5035 - part 44H7779.
Note: FC 5035 may contain up to 4 power supplies. The reference code that sent you here refers
to the power supply on the base expansion unit. See Expansion Unit Locations and Addresses in
the Migrated Expansion Tower Problem Analysis, Repair and Parts manual on the V5R1
Supplemental Manuals web site .
This ends the procedure.
8. Is the SRC 1xxx 2133, 2143, 2153, 2313, or 2333?
v No: Continue with the next step.
v Yes: The failing item is power supply 3 on a internal expansion unit: FC 5034, 5035 - part
44H7777
Note: FC 5035 may contain up to four power supplies. The reference code that sent you here
refers to the power supply on the base expansion unit. See Expansion Unit Locations and
Addresses in the Migrated Expansion Tower Problem Analysis, Repair and Parts manual on the
V5R1 Supplemental Manuals web site .
This ends the procedure.
9. Is the SRC 1xxx 2134, 2144, 2154, 2314, or 2334?
v No: Continue with the next step.
v Yes: The failing item is power supply 4 on the expansion unit of an FC 5035 system - part
44H7777.
Note: FC 5035 may contain up to 4 power supplies. The reference code that sent you here refers
to the power supply on the base expansion unit. See Expansion Unit Locations and Addresses in
the Migrated Expansion Tower Problem Analysis, Repair and Parts manual on the V5R1
Supplemental Manuals web site .
This ends the procedure.
10.
Is the SRC 1xxx 2141, 2151, or 2211?
v No: Continue with the next step.
v Yes: The failing item is power supply 1 on a base expansion unit:
434 iSeries: iSeries Server 270, 800, 810, 820, 825, 830, 840, 870, 890, SB2, and SB3 Hardware Problem Analysis and
Isolation
