IBM iSeries 820

Position FRU name
Possible failing
component
Type, CCIN, or part
number (use the Type,
model, and part
number list to
determine the part
number when the type
or CCIN are given.) Remove and replace procedure
M11 -
M15
Memory card Memory card 3195 (See page 529),
3196 (See page 529),
3197 (See page 529),
3198 (See page 529),
319A (See page 529),
31A1 (See page 529),
3612 (See page 529),
3613 (See page 529), or
3614 (See page 529)
Go to Models 840/SB3, FC 8079
(lower half), FC 9079 Cards —
Dedicated.
M16 Processor
card 3
- OR -
Processor
terminator /
Passthru card
Processor card
- OR -
Processor terminator /
Passthru card
245E (See page 522) or
246E (See page 523)
- OR -
246C (See page 523)
Go to Models 840/SB3, FC 8079
(lower half), FC 9079 Cards —
Dedicated.
M17 Network
Interface
Controller
(NIC)
Network Interface
Controller (NIC)
2737 (See page 524),
2755 (See page 525),
2759 (See page 525)
Go to Models 840/SB3, FC 8079
(lower half), FC 9079 Cards —
Dedicated.
M17
ports
HSL controller
ports
See Figure 5. Network
Interface Controller (NIC)
port locations (See page
281) below.
N/A N/A
M18 Processor
card 1
- OR -
Processor
terminator /
Passthru card
Processor card
- OR -
Processor terminator /
Passthru card
245E (See page 522) or
246E (See page 523)
- OR -
246C (See page 523)
Go to Models 840/SB3, FC 8079
(lower half), FC 9079 Cards —
Dedicated.
M19
M19-
Daughter
card
Clock card
Oscillator card
Clock card
Oscillator card:
25AA (See page 523)
25AC (See page 523)
OR 25AF (See page
523)
Go to Models 840/SB3, FC 8079
(lower half), FC 9079 Cards —
Dedicated.
M20 -
M24
Memory card Memory card 3195 (See page 529),
3196 (See page 529),
3197 (See page 529),
3198 (See page 529),
319A (See page 529),
31A1 (See page 529),
3612 (See page 529),
3613 (See page 529), or
3614 (See page 529)
Go to Models 840/SB3, FC 8079
(lower half), FC 9079 Cards —
Dedicated.
R11 Regulator
card
Regulator card 21H7763 Go to Models 840/SB3, FC 8079
(lower half), FC 9079 Cards —
Dedicated.
274 Hardware (Remove and Replace; Part Locations and Listings)
