Locations - 2892 Integrated xSeries Server (IXS): Use Figure 2. below to find locations for the 2892
Integrated xSeries Server (IXS).
Figure 2. Locations - 2892 Integrated xSeries Server (IXS)
Addresses — Model 270
For use by authorized service providers.
Use the address to find the location. Then, go to Locations — Model 270 for additional information.
Table 1. IOP, IOA, and device address information for Model 270
Position (listed in IOA
assignment order)
Possible failing
component DSA (BBBBCcbb) Unit address
Note: IOA and device
DSA’s will not follow the
rules below if the IOA is
manually reassigned after
IPL.
MB1 Embedded IOP 0001-10-00 FFFFFFFF
322 Hardware (Remove and Replace; Part Locations and Listings)
