Possible failing
component
FRU name Position Type or CCIN
number (see the
Type, model, and
part number list)
Remove and
replace
procedure
Additional
comments
System processor System processor M11, M14, M16,
M21
25D3 (See page
524)
Go to Models 870
and 890 - MCM
module
(processor) and
pass-through
modules
Memory card Memory card M01, M02, M07,
M08, M17, M18,
M24, M25
3015 (See page
528), 3016 (See
page 528), 3017
(See page 528),
3018 (See page
528), 3020 (See
page 528), 3021
(See page 528),
3035 (See page
529), or 3036
(See page 529).
Go to Models 870
and 890 -
Memory books
and memory
blanks
Interactive card Interactive card M41-B 1576 (See page
521), 1577, 1578
(See page 521),
1579 (See page
521), 1581 (See
page 521), 1583
(See page 521),
1585 (See page
521), 1587 (See
page 521), 1588
(See page 521),
or 1591 (See
page 521)
Go to Models 870
and 890 - VPD
card.
Capacity card Capacity card M41-A 0197 (See page
520), 0198 (See
page 520), 2487
(See page 523),
or 2488 (See
page 523)
Go to Models 870
and 890 - VPD
card.
MCM VPD card MCM VPD card M41-D, M41-E,
M41-F, M41-G
See the Type,
model, and part
number list
Go to Models 870
and 890 - VPD
card.
L3 VPD card L3 VPD card M41-C 25F1 (See page
524)
Go to Models 870
and 890 - VPD
card.
L3 cache card L3 cache card M03, M04, M05,
M06, M09, M10,
M12, M13, M19,
M20, M22, M23,
M26, M27, M28,
M29
25F1 (See page
524)
Go to Models 870
and 890 - L3
modules.
Network interface
controller (NIC)
Network interface
controller (NIC)
card
M30, M39, M40 2776 (See page
525), or 2788
(See page 526)
See Models 870
and 890 -
Network interface
controller (NIC)
card
Analyze hardware problems 289
