IBM iSeries 820 Service Manual

Position Possible failing
component
DSA (BBBBCcbb) Unit address
D05 Disk unit The disk unit has the same
DSA as the IOA attached to
the internal cable labelled
″L-1″.
x00700FF (where x is the
same as the first character
of the xFFFFFFF IOA Unit
Address)
D06 Disk unit The disk unit has the same
DSA as the IOA attached to
the internal cable labelled
″R-2″.
x00300FF (where x is the
same as the first character
of the xFFFFFFF IOA Unit
Address)
D07 Disk unit The disk unit has the same
DSA as the IOA attached to
the internal cable labelled
″R-2″.
x00400FF (where x is the
same as the first character
of the xFFFFFFF IOA Unit
Address)
D08 Disk unit The disk unit has the same
DSA as the IOA attached to
the internal cable labelled
″R-2″.
x00500FF (where x is the
same as the first character
of the xFFFFFFF IOA Unit
Address)
D09 Disk unit The disk unit has the same
DSA as the IOA attached to
the internal cable labelled
″R-2″.
x00600FF (where x is the
same as the first character
of the xFFFFFFF IOA Unit
Address)
D10 Disk unit The disk unit has the same
DSA as the IOA attached to
the internal cable labelled
″R-2″.
x00700FF (where x is the
same as the first character
of the xFFFFFFF IOA Unit
Address)
D11 Disk unit The disk unit has the same
DSA as the IOA attached to
the internal cable labelled
″L-1″.
x10300FF (where x is the
same as the first character
of the xFFFFFFF IOA Unit
Address)
D12 Disk unit The disk unit has the same
DSA as the IOA attached to
the internal cable labelled
″L-1″.
x10400FF (where x is the
same as the first character
of the xFFFFFFF IOA Unit
Address)
D13 Disk unit The disk unit has the same
DSA as the IOA attached to
the internal cable labelled
″L-1″.
x10500FF (where x is the
same as the first character
of the xFFFFFFF IOA Unit
Address)
D14 Disk unit The disk unit has the same
DSA as the IOA attached to
the internal cable labelled
″L-1″.
x10600FF (where x is the
same as the first character
of the xFFFFFFF IOA Unit
Address)
D15 Disk unit The disk unit has the same
DSA as the IOA attached to
the internal cable labelled
″L-1″.
x10700FF (where x is the
same as the first character
of the xFFFFFFF IOA Unit
Address)
D16 Disk unit The disk unit has the same
DSA as the IOA attached to
the internal cable labelled
″R-2″.
x10300FF (where x is the
same as the first character
of the xFFFFFFF IOA Unit
Address)
D17 Disk unit The disk unit has the same
DSA as the IOA attached to
the internal cable labelled
″R-2″.
x10400FF (where x is the
same as the first character
of the xFFFFFFF IOA Unit
Address)
334 Hardware (Remove and Replace; Part Locations and Listings)
