IBM iSeries 820

Index Part number Units Description
1 21H7512 1 Cover, right side
2 1621811 8 Screw, 4M (10mm)
3 21H7209 1 Cover assembly, lower front
4 23L3636 1 Cover, middle front
5 21H7213 1 Cover, left side
6 1621811 8 Screw, 4M (10mm)
7 21H7208 1 Cover, upper front
8 21H7523 2 EMC access plate
9 21H7211 1 Cover, top
10 1621811 4 Screw, M4 (10mm)
11 23L3653 1 Cover, upper rear
12 23L3654 1 Cover, upper rear
13 23L3652 1 Upper hinge pin
Final assembly, front - Models 840 and SB3 Processor Tower: For use by authorized service providers.
Figure 1. Final assembly, front - Models 840 and SB3 Processor Tower
Analyze hardware problems 411
