Index Part number Units Description
14 04N2662 1 EMC access plate, rear air
moving device (AMD)
15 1621811 4 Screw, M4 (10mm)
16 21H6959 2 Air moving device (AMD)
assembly (AMD B03 and
AMD B04)
17 1621811 8 Screw, M4 (10mm)
18 23L3646 1 Bracket, cable
19 1621811 2 Screw, M4 (10mm)
20 97P2348 1 Power subframe assembly
for single line cord
20 21P4079 1 Power subframe assembly
for dual line cord
21 1621811 7 Screw, M4 (10mm)
22 21H7000 1 AC box-domestic 1 phase.
Quantity of two for dual line
cord
- 21H7261 1 AC box world trade (WT) 1
phase
- 21H7264 1 AC box WT 2 phase
23 1621811 Screw, M4 (10mm)
24 21H7080 1 Battery assembly
25 1621811 4 Screw, M4 (10mm)
26 23L3640 1 Battery charger assembly
27 1621811 2 Screw, M4 (10mm)
28 21H7518 1 EMC access plate, battery
backup
29 1621811 6 Screw, M4 (10mm)
30 04N6092 1 Concurrent maintenance
adapter card - dual line
cord system
31 1621811 6 Screw, M4 (10mm)
Figure 3. Final assembly, rear - Models 840 and SB3 Processor Tower, continued
Analyze hardware problems 417
