Control panel assembly, processor tower - Models 840 and SB3: For use by authorized service providers.
Figure 1. Control panel assembly, processor tower - Models 840 and SB3
Table 1. Control panel assembly, processor tower - Models 840 and SB3
Index Part number Units Description
1 AR 1 Processor capacity card
(slot A). See the Type,
model, and part number list.
2 AR 1 Interactive card (slot B).
See the Type, model, and
part number list.
3 NONUM AR Processor capacity access
cover
NONUM AR Control panel connector
cover
23L3469 1 Control panel card
assembly
23L3537 1 Control panel overlay
Analyze hardware problems 419
