Index Part number Units Description
41 53P1038 2 Power supply — 840 watts (P01, P02)
42 53P4651 1 Power sub frame assembly
43 1621811 12 Screw, M4 (10mm)
44 24L0940 AR Filler, spacer
45 1621811 2 Screw, M4 (10mm)
46 24L0939 AR Filler, power supply
47 1621811 2 Screw, M4 (10mm)
48 NONUM 1 EMC access plate
49 1621811 2 Screw, M4 (10mm)
50 44H8641 2 Cable clamp, Top
51 44H8640 2 Cable clamp, base
52 1621811 2 Screw, M4 (10mm)
Figure 6. Final assembly (continued) - FC 9079 Base I/O Tower (Models 840 and SB3 - single line
cord)
Table 6. Final assembly (continued) - FC 9079 Base I/O Tower (Models 840 and SB3 - single line
cord)
428 Hardware (Remove and Replace; Part Locations and Listings)
