Table 1. Cover assembly - FC 5074, FC 5094
Index Part number Units Description
1 24L0825 1 Top cover
2 1621811 4 Screw, M4 (10mm)
3 24L1079
24L1071
1 Rear cover
Hinge pin, top
4 24L0824 1 Side cover
5 1621811 12 Screw, M4 (10mm)
450 Hardware (Remove and Replace; Part Locations and Listings)
