IBM iSeries 820

Index Part number Units Description
5 53P0330 1 Display Panel tray
assembly
6 53P1457 1 Cover assembly, front
7 53P2572 1 Latch assembly, left
7a 75G2878 2 Screw, M3.5 x 8mm
8 53P0296 1 General location, but not
shown. Cable management
arm
8a 53P3451 1 Slide assembly, left side
8b 53P3452 1 Slide assembly, right side
8c 53P3726 AR Rail mounting hardware
Figure 2. Final assembly - FC 0595 rack mounted expansion unit, continued
Table 2. Final assembly - FC 0595 rack mounted expansion unit, continued
476 Hardware (Remove and Replace; Part Locations and Listings)
